Installation Instructions
PowerFlex 700H and 700S Frame 9 Drive Lifting Instructions
This document provides instructions for lifting frame 9 PowerFlex 700H and
PowerFlex 700S AC drives.
Frame 9 - Approximate Drive and Enclosure Weights
ATTENTION: Follow these precautions to guard against possible personal injury
and/or equipment damage.
• Remove any wiring access covers at the top of the drive.
• Do Not allow any part of the drive or lifting mechanism to make contact with
electrically charged conductors or components.
• At no time should a person or their limbs be directly underneath the items
being lifted.
• Do not subject the load to high rates of acceleration or deceleration.
• Inspect all lifting hardware for proper attachment before lifting drive unit.
Voltage Class Drive Rating
Amps
AC Input Drive &
Enclosure Weight
kg (lbs)
AC Input Drive, Enclosure
& Packaging Weight
kg (lbs)
DC Input Drive &
Enclosure Weight
kg (lbs)
DC Input Drive, Enclosure
& Packaging Weight
kg (lbs)
400/480V AC
(540/650V DC)
261 143 (315) 205 (452) 109 (240) 171 (377)
400/480V AC
(540/650V DC)
300 151 (333) 213 (470) 117 (258) 179 (395)
600/690V AC
(810/932V DC)
170 143 (315) 205 (452) 109 (240) 171 (377)
600/690V AC
(810/932V DC)
208 143 (315) 205 (452) 109 (240) 171 (377)
