Appendix A HIM Overview
Diagnostics Menu
When a fault trips the drive, use this menu to access detailed data about the drive:
Parameter Menu
See View and Edit Parameters on page 85.
Device Select Menu
Use this menu to access parameters in connected peripheral devices.
Memory Storage Menu
Drive data can be saved to, or recalled from, User and HIM sets.
User sets are files stored in permanent nonvolatile drive memory.
HIM sets are files stored in permanent nonvolatile HIM memory.
Start Up Menu
See Chapter 1.
Preferences Menu
The HIM and drive have features that you can customize.
Option Description
Faults View fault queue or fault information, clear faults or reset drive.
Status Info View parameters that display status information about the drive.
Device Version View the firmware revision and hardware series of components.
HIM Version View the firmware revision and hardware series of the HIM.
Option Description
HIM Copycat
Device -> HIM
Device <- HIM
Save data to a HIM set, load data from a HIM set to active drive memory
or delete a HIM set.
Device User Sets Save data to a User set, load data from a User set to active drive
memory or name a User set.
Reset To Defaults Restore the drive to its factory-default settings.
Option Description
Drive Identity Add text to identify the drive.
Change Password Enable/disable or modify the password.
User Dspy Lines Select the display, parameter, scale and text for the user display. The user display is two lines
of user-defined data that appears when the HIM is not being used for programming.
User Dspy Time Set the wait time for the user display or enable/disable it.
User Dspy Video Select Reverse or Normal video for the Frequency and user display lines.
Reset User Dspy Return all the options for the user display to factory default values.
