COMMUNICATIONS
Security
597 [Write Mask Act]
Status of write access for DPI ports. When bit 15 is set, network
security is controlling the write mask instead of parameter 596
[Write Mask Cfg].
Note: Added for firmware revision 4.001.
1 = Write Permitted
0 = Read Only
Read Only
598 [Logic Mask Act]
Indicates status of the logic mask for DPI ports. When bit 15 is
set, network security is controlling the logic mask instead of
parameter 276 [Logic Mask].
Note: Added for firmware revision 4.001.
1 = Control Permitted
0 = Control Masked
Read Only
File Group No.
Parameter Name & Description Values
Related
Name Security Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved DPI Port 6 DPI Port 5 DPI Port 4 DPI Port 3 DPI Port 2 DPI Port 1 Host
Default0xxxxxxxx0000000
Bit 1514131211109876543210
Name Security Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved DPI Port 6 DPI Port 5 DPI Port 4 DPI Port 3 DPI Port 2 DPI Port 1 Digital In
Default0xxxxxxxx0000000
Bit 1514131211109876543210
File Group No.
Parameter Name & Description Values
Related
INPUTS/OUTPUTS
Analog Inputs
320 [Anlg In Config]
Selects the mode for the analog inputs.
1 = Current
0 = Voltage
322
325
323
326
Name Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved An2 0=V 1=mA An1 0=V 1=mA
Defaultxxxxxxxxxxxxxx00
Bit 1514131211109876543210
