707 Simulator torque no filtering
708 Position 1 detected during reconnect
709 Position 2 detected during reconnect
710 Position 3 detected during reconnect
711 Position 4 detected during reconnect
712 Position 5 detected during reconnect
713 Full stroke average torque
714 Pump off trip level 1, x100
715 Pump off trip level 2
716 Pump off trip level 3
717 Position used when in full stroke average mode
720 Holds speed reference during startup
721 This shows the sleep time used for pump off, it is parameter 183
722 Counts number of times position reconnect restarted
723 Counts number of sleep states, same as parameter 690
728 Elapsed time in current day 0.0001 hours
729 The start time for a 24-hour cycle, used to determine day
730 Pointer to arrays of data
731 (0…13)
• Number of pump off counts in the past 24 hours that the drive was powered.
This changes during the current day.
• Number of pump off counts in the previous 13 days.
The count is pushed down at the end of each day.
Number 1 is the previous day, and 13 is 13 days ago.
732 (0…13) Stroke count for the current 24-hour period. Full stroke count for previous days.
733 (0…23) Stroke count per hour, updated once per hour. “0” is the most current.
734 (0…23) Downstroke or cycle torque, updated once per hour. “0” is the most current.
Test Points (cont.)
Test Point Description
