644 Baseline torque, calculated on first run or when commanded speed is changed
645 Pump off trip level, x100
646 Pump off detector current value, x100
647 Speed used during pump off
648 Baseline torque after 1st spd change
649 Pump off trip level 1st change
650 Commanded speed
651 Pump jack state:
0 = Initialize baseline torque levels
1 = Running
2 = Delay before returning to run after pump off
3 = Pump off 1 baseline
4 = Pump off 1 run/wait
5 = Pump off 2 baseline
6 = Pump off 2 run/wait
7 = Pump off sleeping/stopped
652 Counter for torque averaging
655 Storage for average torque value
656 Parameter 682 – Pump Off Control
657 Pump off control state
659 Down average calc
660 Up average calc
661 Output frequency
662 Maximum speed detected during cycle
665 Position with top of stroke offset
666 Peak 1 torque
667 Peak 1 position
668 Peak 2 torque
669 Peak 2 position
670 Valley 1 torque
671 Valley 1 rising position
672 Valley 1 min position
673 Valley 2 torque
674 Valley 2 rising position
675 Valley 2 min position
Test Points (cont.)
Test Point Description
