PowerFlex 700 Parameter Record
Machine #
Date programmed
Par Parameter Name Minimum Value Maximum Value Factory Default Programmed Value
285 Local Mask Digital In 1
DPI Port 1 1
DPI Port 2 1
DPI Port 3 1
Unused X
DPI Port 5 1
288 Stop Owner Digital In 1
DPI Port 1 0
DPI Port 2 0
DPI Port 3 0
Unused X
DPI Port 5 0
289 Start Owner Digital In 1
DPI Port 1 0
DPI Port 2 0
DPI Port 3 0
Unused X
DPI Port 5 0
290 Jog Owner Digital In 1
DPI Port 1 0
DPI Port 2 0
DPI Port 3 0
Unused X
DPI Port 5 0
291 Direction Owner Digital In 1
DPI Port 1 0
DPI Port 2 0
DPI Port 3 0
Unused X
DPI Port 5 0
292 Reference Owner Digital In 1
DPI Port 1 0
DPI Port 2 0
DPI Port 3 0
Unused X
DPI Port 5 0
293 Accel Owner Digital In 1
DPI Port 1 0
DPI Port 2 0
DPI Port 3 0
Unused X
DPI Port 5 0
294 Decel Owner Digital In 1
DPI Port 1 0
DPI Port 2 0
DPI Port 3 0
Unused X
DPI Port 5 0
295 Fault Clr Owner Digital In 1
DPI Port 1 0
DPI Port 2 0
DPI Port 3 0
Unused X
DPI Port 5 0
296 MOP Owner Digital In 1
DPI Port 1 0
DPI Port 2 0
DPI Port 3 0
Unused X
DPI Port 5 0
297 Local Owner Digital In 1
DPI Port 1 0
DPI Port 2 0
DPI Port 3 0
Unused X
DPI Port 5 0
300 Data In A1 0 387 0
301 Data In A2 0 387 0
302 Data In B1 0 387 0
303 Data In B2 0 387 0
304 Data In C1 0 387 0
305 Data In C2 0 387 0
306 Data In D1 0 387 0
307 Data In D2 0 387 0
310 Data Out A1 0 387 0
311 Data Out A2 0 387 0
312 Data Out B1 0 387 0
313 Data Out B2 0 387 0
314 Data Out C1 0 387 0
315 Data Out C2 0 387 0
316 Data Out D1 0 387 0
317 Data Out D2 0 387 0
320 Anlg In Config Analog In 1 0
Analog In 2 0
321 Anlg In Sqr Root Analog In 1 0
Analog In 2 0
322 Analog In 1 Hi
4.000 mA
20.000 mA
10.0 Volt
-10.0 V
+10.0 V
0.0V
10.0 V
323 Analog In 1 Lo
4.000 mA
20.000 mA
0.0 Volt
-10.0V
+10.0V
0.0V
10.0V
324 Analog In 1 Loss
Disabled
Disabled
Fault
Hold Input
Set Input Lo
Set Input Hi
Goto Preset1
Hold OutFreq
325 Analog In 2 Hi
4.000 mA
20.000 mA
10.0 Volt
-10.0 V
+10.0 V
0.0
10.0 V
326 Analog In 2 Lo
4.000 mA
20.000 mA
0.0 Volt
-10.0V
+10.0V
0.0V
10.0V
327 Analog In 2 Loss
Disabled
Disabled
Fault
Hold Input
Set Input Lo
Set Input Hi
