PowerFlex 700 Parameter Record
Machine #
Date programmed
Drive Serial #
Par Parameter Name Minimum Value Maximum Value Factory Default Programmed Value
212 Drive Alarm 2 DigIn CflctA 0
DigIn CflctB 0
DigIn CflctC 0
Bipolr Cflct 0
MtrTyp Cflct 0
NP Hz Cflct 0
MaxFrq Cflct 0
VHz NegSlope 0
IR Vlts Rang 0
FlxAmps Rang 0
SpdRef Cflct 0
213 Speed Ref Source PI Output Read Only
Analog In 1
Analog In 2
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
MOP Level
Jog Speed
Preset Spd1
Preset Spd2
Preset Spd3
Preset Spd4
Preset Spd5
Preset Spd6
Preset Spd7
DPI Port 1
DPI Port 2
DPI Port 3
Reserved
DPI Port 5
214 Start Inhibits Faulted 1
Type 2 Alarm 0
Enable 0
DC Bus Pchrg 0
Stop Assertd 1
Params Reset 0
Startup Actv 0
Unused X
Digital In 1
DPI Port 1 0
DPI Port 2 0
DPI Port 3 0
Unused X
DPI Port 5 0
Unused X
Unused X
215 Last Stop Source Pwr Removed Read Only
DPI Port 1
DPI Port 2
DPI Port 3
Reserved
DPI Port 5
Reserved
Digital In
Fault
Not Enabled
Sleep
Jog
216 Dig In Status Digital In1 0
Digital In2 0
Digital In3 0
Digital In4 0
Digital In5 0
Digital In6 0
217 Dig Out Status Digital Out1 0
Digital Out2 0
218 Drive Temp
0.0
100.00%
Read Only
219 Drive OL Count
0.0
100.00%
Read Only
220 Motor OL Count
0.0
100.00%
Read Only
224 Fault Frequency 0.0 +[Maximum Freq] Read Only
225 Fault Amps 0.0 Amps [Rated Amps] x 2 Read Only
226
Fault Bus Volts
0.0 VDC
Max Bus Volts
Read Only
