PowerFlex 700 Parameter Record
Machine #
Date programmed
Drive Serial #
Par Parameter Name Minimum Value Maximum Value Factory Default Programmed Value
90 Speed Ref A Sel Analog In 1 Analog In 2
Analog In 2
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
MOP Level
Reserved
Preset Spd1
Preset Spd2
Preset Spd3
Preset Spd4
Preset Spd5
Preset Spd6
Preset Spd7
DPI Port 1
DPI Port 2
DPI Port 3
Reserved
DPI Port 5
91 Speed Ref A Hi
- [Maximum Speed]
+ [Maximum Speed]
[Maximum Speed]
92 Speed Ref A Lo
- [Maximum Speed]
+ [Maximum Speed]
0.0 Hz
93 Speed Ref B Sel Analog In 1 Preset Spd1
Analog In 2
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
MOP Level
Reserved
Preset Spd1
Preset Spd2
Preset Spd3
Preset Spd4
Preset Spd5
Preset Spd6
Preset Spd7
DPI Port 1
DPI Port 2
DPI Port 3
Reserved
DPI Port 5
94 Speed Ref B Hi
- [Maximum Speed]
+ [Maximum Speed]
[Maximum Speed]
95 Speed Ref B Lo
- [Maximum Speed]
+ [Maximum Speed]
0.0 Hz
96 TB Man Ref Sel Analog In 1 Analog In 1
Analog In 2
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
MOP Level
97 TB Man Ref Hi
- [Maximum Speed]
+ [Maximum Speed]
[Maximum Speed]
98 TB Man Ref Lo
- [Maximum Speed]
+ [Maximum Speed]
0.0 Hz
100 Jog Speed
- [Maximum Speed]
+ [Maximum Speed]
10.0 Hz
101 Preset Speed 1
- [Maximum Speed]
+ [Maximum Speed]
5.0 Hz
102 Preset Speed 2
- [Maximum Speed]
+ [Maximum Speed]
10.0 Hz
103 Preset Speed 3
- [Maximum Speed]
+ [Maximum Speed]
20.0 Hz
104 Preset Speed 4
- [Maximum Speed]
+ [Maximum Speed]
30.0 Hz
105 Preset Speed 5
- [Maximum Speed]
+ [Maximum Speed]
40.0 Hz
106 Preset Speed 6
- [Maximum Speed]
+ [Maximum Speed]
50.0 Hz
107
Preset Speed 7
- [Maximum Speed]
+ [Maximum Speed]
60.0 Hz
