Kinetix 7000 Drive Systems
Bulletin MPM Motor Performance Specifications with Kinetix 7000 (400V class) Drives
Performance specification data and curves reflect nominal system performance of a typical system with motor at 40 °C (104 °F) and drive at 50 °C (122 °F) ambient and rated line voltage. For additional
information on ambient and line conditions, refer to Motion Analyzer software, version 4.7 or later.
Rotary Motor
Speed,
base
rpm
Speed,
max
rpm
System Continuous
Stall Current
A 0-pk
System Continuous
Stall Torque
N•m (lb•in)
System Peak
Stall Current
A 0-pk
System Peak
Stall Torque
N•m (lb•in)
Motor Rated
Output
kW
Kinetix 7000
400V-class Drives
MPM-B1651M 4500 5000 22.46 11.3 (100) 56.8 21.4 (189) 2.50 2099-BM06-S
MPM-B1652E 2250 3500 20.94 21.1 (187) 60.5 48.0 (425) 4.30 2099-BM06-S
MPM-B1652F 3000 4500 28.74 21.1 (187) 84.1 45.0 (398) 4.30 2099-BM06-S
MPM-B1653C 1500 2500 20.05 26.7 (236) 59.2 67.7 (599) 4.60 2099-BM06-S
MPM-B1653E 2250 3500 27.0 26.8 (237) 72.9 62.0 (549) 5.10 2099-BM06-S
MPM-B1653F 3000 4000 34.94 31.0 (274) 94.3 56.1 (496) 5.10 2099-BM06-S
MPM-B2152C 1500 2500 27.40 36.7 (325) 55.4 72.2 (639) 5.60 2099-BM06-S
MPM-B2152F 3000 4500 43.54 34.1 (302)
96.0 70.8 (626)
5.90
2099-BM06-S
98.0 72.2 (639) 2099-BM07-S
MPM-B2152M 4500 5000 44.58 34.1 (302) 76.3 52.9 (468) 5.90 2099-BM06-S
MPM-B2153B 1250 2000 24.06 48.0 (425) 60.0 101 (895) 6.80 2099-BM06-S
MPM-B2153E 2250 3000 39.63 47.9 (424)
96.0 98.8 (468)
7.20
2099-BM06-S
98.6 101 (895) 2099-BM07-S
MPM-B2153F 3000 3800 43.86 45.6 (403)
96.0 96.6 (855)
7.20
2099-BM06-S
98.4 98.9 (875) 2099-BM07-S
MPM-B2154B 1250 2000 35.46 62.7 (555)
96.0 151 (1336)
6.90
2099-BM06-S
98.0 154 (1363) 2099-BM07-S
MPM-B2154E 2250 3000 43.68 55.9 (495)
96.0 110 (973)
7.50
2099-BM06-S
98.3 112 (991) 2099-BM07-S
MPM-B2154F 3000 3300 44.40 56.2 (497) 83.6 87.9 (778) 7.50 2099-BM06-S
