Installation Instructions Instruction Manual

Publication 2093-IN003A-MU-P - December 2006
Copyright © 2006 Rockwell Automation, Inc. All rights reserved. Printed in the U.S.A.
Mount Slot Fillers
This procedure assumes you have mounted your power rail, integrated axis module, axis
modules, or shunt module (catalog numbers 2093-AC05-MPx, 2093-AMPx, 2093-AM0x, and
2093-ASP06).
Follow these steps to mount a slot filler module on the Kinetix 2000 power rail.
1. Determine which power rail slot requires a slot filler module.
2. Insert the module in the appropriate power rail slot.
a. Align the module locking screw with its corresponding slot on the power rail.
b. Push the module straight forward, by applying force at the top and bottom of the
module.
The module is fully seated when the locking clip snaps into the bottom of the power
rail, and the locking screw boss is flush at the top of the power rail.
3. Torque the mounting screw to 0.7 Nm (6 lb-in).
4. Repeat this procedure as required to install a slot filler in any empty slots on the
power rail.
Allen-Bradley, Kinetix, and Rockwell Automation are trademarks of Rockwell Automation, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
SHOCK HAZARD
To avoid personal injury due to electrical shock, place a slot filler
module in any empty slot on the Kinetix 2000 power rail.
An unoccupied slot in the power rail will disable the Kinetix 2000
system, but control ac power will continue to be applied to the
power rail.
