Kinetix 2000 Drive Systems
Kinetix 2000 Input Power Example (with LIM module)
Kinetix 2000 Input Power Example (without LIM module)
MAIN VAC
Three-phase
Input Power
230V Control Power
2090-XXLF-TCxxx
AC Line Filter
(optional component)
2094-ALxxS
Line Interface Module
(optional component)
I/O Connections
To Input Sensors
and Control String
2093-ASP06
Shunt Module
(optional component)
2093-PRF Slot Filler Module
(required to fill any unused slots)
2093-K2CK-COMBO
Low-profile Connector Kit
(optional component)
2093-K2CK-D15M
Low-profile Connector Kit
(optional component)
2093-K2KSCLAMP-4
Cable Clamp Bracket Kit
(optional component)
2093-AMxx
Axis Modules (4)
2093-AC05-MPx
Integrated Axis Module
Power Rail
2093-PRSx
Input
Fusing
Three-phase
Input Power
230V Control Power
2090-XXLF-TCxxx
AC Line Filter
(optional component)
I/O Connections
To Input Sensors
and Control String
2093-ASP06
Shunt Module
(optional component)
2093-K2CK-COMBO
Low-profile Connector Kit
(optional component)
2093-PRF Slot Filler Module
(required to fill any unused slots)
2093-AC05-MPx
Integrated Axis Module
Power Rail
2093-PRSx
2093-AMxx
Axis Modules (4)
Line
Disconnect
Device
Magnetic
Contactor
Input
Fusing
