Power with Brake Connector Kit for TL-Series Servo Motors Installation Instructions 3
Publication 2090-IN018A-EN-P - June 2010
Before You Begin
Identify the wire colors and pinouts specific to your TL-Series (Bulletin TLY) motor by
referring to the Power Connector information on page
6.
You should also refer to the manual for your drive to determine pinouts and wire connections
appropriate to these connections.
TL-Series (Bulletin TLY) motors are compatible with these Allen-Bradley drives:
Kinetix 300
Kinetix 2000
Kinetix 6000
Kinetix 6200
Kinetix 6500
Ultra3000
Ultra5000
Refer to the Parts List on page
4 for wire sizes compatible with this connector kit.
ATTENTION: To prevent electrical shock, disconnect the connector, motor, and
drive from the power source before installing or servicing.
This device should be used only in an enclosure that prevents exposure to
contaminants.
ATTENTION: When installing a cable, restrain it so that uneven tension or
flexing at the connector does not occur.
Excessive and uneven force at the cable connector may result in damage to the
housing and contacts as the cable flexes.
Failure to observe this safety procedure could result in damage to the motor
and its components.
