Power with Brake Connector Kit forTL-Series (Bulletin TLY) Servo Motors Installation Instructions, 2090-IN018A-EN-P June 2010

Installation Instructions

Power with Brake Connector Kit for

TL-Series (Bulletin TLY)

Servo Motors

Catalog Number 2090-KPBM6-16AA

About the TL-Series Power with Brake Connector Kit

Use this connector kit to build your own power cable, or power with brake cable,

for use with any of these TL-Series servo motors:

Topic Page

About the TL-Series Power with Brake Connector Kit 1

Important User Information 2

Before You Begin 3

Assemble the Power with Brake Connector Kit 5

Power Connector 6

Additional Resources 7

IMPORTANT

This kit is compatible only with power cables from a TLY-A110, TLY-A120, TLY-A130,

TLY-A220, TLY-A230, TLY-A2530, TLY-A2540, or TLY-A310 servo motor.

Summary of content (8 pages)

PAGE 1
Installation Instructions Power with Brake Connector Kit for TL-Series (Bulletin TLY) Servo Motors Catalog Number 2090-KPBM6-16AA Topic Page About the TL-Series Power with Brake Connector Kit 1 Important User Information 2 Before You Begin 3 Assemble the Power with Brake Connector Kit 5 Power Connector 6 Additional Resources 7 About the TL-Series Power with Brake Connector Kit Use this connector kit to build your own power cable, or power with brake cable, for use with any of these TL-Series
PAGE 2
Power with Brake Connector Kit for TL-Series Servo Motors Installation Instructions Important User Information Solid state equipment has operational characteristics differing from those of electromechanical equipment. Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls (publication SGI-1.1 available from your local Rockwell Automation sales office or online at http://rockwellautomation.
PAGE 3
Power with Brake Connector Kit for TL-Series Servo Motors Installation Instructions 3 Before You Begin Identify the wire colors and pinouts specific to your TL-Series (Bulletin TLY) motor by referring to the Power Connector information on page 6. ATTENTION: To prevent electrical shock, disconnect the connector, motor, and drive from the power source before installing or servicing. This device should be used only in an enclosure that prevents exposure to contaminants.
PAGE 4
Power with Brake Connector Kit for TL-Series Servo Motors Installation Instructions Parts List These items are supplied in the connector kit. Item Qty. Power sockets 8 Brake sockets 15 Housing 1 N/A 205839-3 Backshell (1) 1 N/A 206070-8 (1) Wire Size Insulation Diameter Insulation Strip Length mm² (AWG) mm (in.) mm (in.) 0.8…1.4 (18…16) 2.54 (0.10) max 2.5 (0.1) Tyco AMP Part No.
PAGE 5
Power with Brake Connector Kit for TL-Series Servo Motors Installation Instructions 5 Assemble the Power with Brake Connector Kit Follow these steps to assemble your TL-Series (Bulletin TLY) connector kit. ATTENTION: To prevent electrical shock, disconnect the connector, motor, and drive from the power source before installing or servicing. This device should be used only in an enclosure that prevents exposure to contaminants. 1. Slide the backshell onto the cable. 2.
PAGE 6
Power with Brake Connector Kit for TL-Series Servo Motors Installation Instructions Power Connector This table shows the pin connections for the power connector on a TL-Series motor.
PAGE 7
Power with Brake Connector Kit for TL-Series Servo Motors Installation Instructions 7 Additional Resources These documents contain additional information about related Rockwell Automation products. Resource Description Kinetix 300 Single-axis Servo Drives User Manual, publication 2097-UM001 How to install, set up, and troubleshoot a servo-drive system.
PAGE 8
Rockwell Automation Support Rockwell Automation provides technical information on the Web to assist you in using its products. At http://www.rockwellautomation.com/support/, you can find technical manuals, a knowledge base of FAQs, technical and application notes, sample code and links to software service packs, and a MySupport feature that you can customize to make the best use of these tools.
