Owner's manual

6 Standard Feedback Cables with SpeedTec DIN Connector Type 623
Publication 2090-IN029A-EN-P - September 2010
2090-CFBM7DF-CEAAxx
This cable is available in several lengths. Refer to the Kinetix Motion Control Selection Guide,
publication GMC-SG001
, for this information and additional specifications.
(1) Wire gauge and connector keying varies based on motor and power requirements. Refer to Kinetix Motion Control Selection
Guide, publication GMC-SG001
, for additional information.
22 AWG Black
22 AWG White/Black
22 AWG Red
22 AWG White/Red
22 AWG Green
22 AWG White/Green
22 AWG Grey
22 AWG White/Grey
22 AWG Orange
22 AWG White/Orange
36 AWG Shield
1
2
3
4
5
6
9
10
11
13
14
12
SIN+/AM+
SIN-/AM-
COS+/BM+
COS-/BM-
DATA+/IM+/R1
DATA-/IM-/R2
EPWR 5V
ECOM
EPWR 9V
TS+
TS-
ECOM
1
2
3
4
5
16
1514
13
12
11
10
9
8
7
6
17
Twisted Wire Pair
360° shield-to-ground
connections required.
To
Motor
Connector Backshell
Shielded 360°
Wire Connection
To
Drive
Shield
