Installation Instructions User Manual

6 Kinetix 6000M Manual Brake Release Cable
Publication 2090-IN037B-EN-P - March 2012
Specifications
Additional specifications for each cable are available in the Kinetix Motion Accessories Technical
Data, publication GMC-TD004.
Additional Resources
These documents contain additional information concerning related products from Rockwell
Automation.
You can view or download publications at http://www.rockwellautomation.com/literature
.
To order paper copies of technical documentation, contact your Allen-Bradley® distributor or
Rockwell Automation® sales representative.
Attribute 2090-CBKS8-16AA03
Wire size 18 AWG
Diameter
(1)
(1) Cable diameter tolerance is ± 0.13 mm (0.005 in.).
8.13 mm (0.320 in.)
Bend radius 97.6 mm (3.84 in.)
Installation areas
(2)
(2) The installation areas are 300 ± 25 (12 in. ± 1.0) in length at both ends of the cable. Secure this area with a rigid mount that prevents the cable
from flexing where it connects to other components.
Resource Description
Kinetix 6000M Integrated Drive-Motor User Manual, publication
2094-UM003
Information on installing, configuring, starting, and
troubleshooting a servo drive system with a servo motor.
Kinetix 6000M Integrated Drive-Motor Installation Instructions,
publication MDF-IN001
Information on the installation of your Kinetix 6000M
integrated drive-motor unit.
Kinetix 6000M Integrated Drive-Motor Power Interface Module
Installation Instructions, publication 2094-IN016
Information on the installation of your Kinetix 6000M
integrated drive-motor power interface module
Allen-Bradley Industrial Automation Glossary, publication
AG-7.1
A glossary of industrial automation terms and abbreviations.
System Design for Control of Electrical Noise Reference Manual,
publication GMC-RM001
Information, examples, and techniques designed to minimize
system failures caused by electrical noise.
Kinetix Rotary Motion Specifications Technical Data,
publication GMC-TD001
Catalog numbers and product specifications, including
performance, environmental, certifications, load force, and
dimension drawings for Allen-Bradley rotary motors.
Kinetix Motion Accessories Technical Data,
publication GMC-TD004
Catalog numbers, specifications, and dimensions for
Allen-Bradley servo drive accessories.
Kinetix Motion Control Selection Guide,
publication GMC-SG001
General product specifications for Kinetix motion control
products.
