Configuring Your Block I/O for
SLC Controllers
Chapter 5
52
Figure 5.1
Switch
Settings for Block I/O when used with the SLC 500 Controller
OUTPUT
INPUT
COMM POWER
OPEN
12 34 56
12 34 56
OPEN
Off (1)
On (0)
56Baud Rate
230.4K
4Hold Last State
Reset to 0
Hold last state
1DH-485
None
Terminate
Block
Addresses
Switches
1 - 6
Not Used
S1 S2
S1 S2
1-7
100000 to 111000
1-15
100000 to 111100
17-31
100010 to 111110
10839-I
Off (1)
On (0)
On (0)
Off (1)
Off = Open = 1
On = Closed = 0
Switch as viewed from this end.
