Chapter
4
41
Configuring Your Block I/O for PLC
Family Programmable Controllers
In this chapter you will learn how to configure your block I/O when used
with PLC family programmable controllers. This includes the following:
setting the configuration switches
addressing the block I/O
Each block I/O module has two 6–position DIP switches for setting:
starting I/O group
I/O rack number
transmission (baud) rate
last chassis
last state
DH–485 terminator
These switches are accessible by opening the door on the left side of the
module (Figure 4.1).
Chapter
Objectives
Setting the Configuration
Switches
