Installing Block I/O
Chapter 3
37
Figure 3.7
Series
Configurations for Block I/O Using the SLC Programmable
Controller
To 1747-DSN
Scanner Module
Up to 7 blocks
using SLC-5/01
Processor
Up to 30 blocks with
SLC-5/02
Install terminating resis
tor
on last block.
Install terminating resis
tor
on last block.
To 1747-DSN
Scanner Module
1
2
29
30
10834-I
