Installation Instructions DeviceNet Digital Base Terminal Block CompactBlock LDX I/O Catalog Numbers 1790D-T16BV0, 1790D-T8BV8V, 1790D-T8BV8B, 1790D-T0B16, 1790D-T0V16, 1790D-T0W6, 1790D-T8A0, 1790D-T0A6, Series A Topic Page Important User Information 2 Prevent Electrostatic Discharge 3 Power Supply 4 Environment and Enclosure 5 North American Hazardous Location Approval 6 Before You Begin 7 Install the Base Block 7 Set the Node Address 7 Mount the Base Block 8 Mount on a Panel 9 Moun
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O Important User Information Solid state equipment has operational characteristics differing from those of electromechanical equipment. Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls (publication SGI-1.1 available from your local Rockwell Automation sales office or online at http://literature.rockwellautomation.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O 3 Prevent Electrostatic Discharge ATTENTION This equipment is sensitive to electrostatic discharge, which can cause internal damage and affect normal operation. Follow these guidelines when you handle this equipment: • Touch a grounded object to discharge potential static. • Wear an approved grounding wriststrap. • Do not touch connectors or pins on component boards. • Do not touch circuit components inside the equipment.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O Power Supply ATTENTION 1790D-T0V16, 1790D-T0B16 To comply with the CE Low Voltage Directive (LVD), the DeviceNet network and outputs must be powered from a source compliant with Safety Extra Low Voltage (SELV) or Protected Extra Low Voltage (PELV). To comply with UL restrictions, the DeviceNet network must be powered from a source compliant with Class 2 or Limited Voltage/Current.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O 5 Environment and Enclosure ATTENTION This equipment is intended for use in a Pollution Degree 2 industrial environment, in overvoltage Category II applications (as defined in IEC publication 60664-1), at altitudes up to 2000 m (6561 ft) without derating. This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR Publication 11.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O North American Hazardous Location Approval The following information applies when operating this equipment in hazardous locations. Informations sur l’utilisation de cet équipement en environnements dangereux. Products marked CL I, DIV 2, GP A, B, C, D are suitable for use in Class I Division 2 Groups A, B, C, D, hazardous locations and nonhazardous locations only.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O 7 Before You Begin Read this section about important CompactBlock requirements. Current functions of CompactBlock LDX I/O blocks require the current, modular electronic data sheet (EDS) file for RSNetWorx for DeviceNet software, version 3.0 or later. These files are are available online at www.ab.com/networks/eds/. EDS files for blocks with matching catalog numbers for both D-Shell and terminal block versions are the same.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O The base block reads the rotary switches only when power is applied. Switch settings between 64 and 99 cause the base block to use the last valid node address stored internally. In this example, the node address setting is 11. 44152 You can also set the node address through RSNetWorx for DeviceNet software or a similar configuration tool. When you use software configuration for the node address, set the switches between 64 and 99.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O 9 Mount on a Panel For panel mounting, use these steps. 1 . Place the block against the panel where you want it mounted. 2. Gently pull and position the expansion cover to the left. 3. Place a center punch, nail, or similar device through the mounting holes in the block and make two marks on the panel at the lower-left and upper-right corners of the module. 4.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O Mount on DIN Rail For DIN-rail mounting, use these steps. 1 . Hook the top slot of the base block over the DIN rail. Locking Lever 44154 2. Pull down on the locking lever while pressing the base block against the rail. 3. Push up on the locking lever to secure the base block to the rail when the base block is flush against the rail.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O 11 Mount your block on a panel or DIN rail. Horizontal Mounting Vertical Mounting The longer expansion cable (1790-15CMCBL) provides for up to 7 cm (2.76 in.) of space in between blocks. 44155 Wire the Terminal Block WARNING If you connect or disconnect wiring while the field-side power is on, an electrical arc can occur. This could cause an explosion in hazardous location installations.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O See the figures for wiring information. 1790D-T16BVO Input Base Block Wiring Diagram IN0 IN4 IN2 1 IN6 3 2 5 4 7 6 IN1 IN8 COM0 IN12 IN10 COM1 IN14 8 IN5 IN3 11 9 12 10 17 15 13 18 16 14 19 20 IN9 COM0 IN13 IN7 IN11 COM1 IN15 44178 For inputs 0…7: For sinking inputs, wire COM 0 (pin 9) to Field Power (-) GND. For sourcing inputs, wire COM 0 (pin 9) to Field Power (+) 24V dc.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O 13 1790D-T8BV8B Input/Output Base Block Wiring Diagram IN0 IN4 1 IN6 3 2 5 4 11 9 8 IN7 19 18 16 14 OUT1 COM IN3 OUT6 17 15 13 12 10 IN5 OUT4 OUT2 VDC 7 6 IN1 OUT0 COM IN2 OUT3 GND 20 OUT5 OUT7 44180 For sinking inputs, wire COM (pin 9) to Field Power (-) GND. For sourcing inputs, wire COM (pin 9) to Field Power (+) 24V dc. Note that COM (pins 9 and 10) are internally connected.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O 1790D-T0W6 Relay Output Base Block Wiring Diagram VDC OUT0 OUT4 OUT2 NC NC OUT1 OUT5 OUT3 1 3 5 2 7 4 GND 11 9 6 8 12 10 19 18 16 14 NC 17 15 13 20 COM0 COM4 COM2 NC NC COM1 COM5 COM3 NC 44183 Wire V dc (pin 1) to Field Power (+) 24V dc. Wire GND (pin 2) to Field Power (-) GND.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O 15 Connect the DeviceNet Cable Follow these procedures to connect the DeviceNet cable to the base block. We do not supply the DeviceNet connector with the base block. You must purchase the connector separately. These are the types of connectors you order directly from Rockwell Automation.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O 2. Attach the connector to the base block once you have properly wired the drop line to the connector. 3. Use the locking screws on the connector to fasten it to the base block, if applicable. Interpret the LED Indicators Read this section for information about how to interpret base block LED indicators. The base block has the following indicators.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O 17 Indication Probable Cause Recommended Action Solid Green The module is operating in a normal condition, and the module is online with connections in the established state. As a group 2 module, the module is allocated to a master. None. Flashing Green The module is online with no connections in the established state. Establish connections to other nodes. As a group 2 module, allocate the module to a master. Off No power.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O All digital-expansion inputs produce data of 1 if the expansion cable is removed. No status is in the produced assembly. Attribute 101 in the identity object reports module faults. If no faults are present, an explicit message GET command returns 0. If the ribbon cable is disconnected, it returns 0x04, which is for module location change. The module LED also flashes indicating a fault if an expansion is disconnected.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O 19 Specifications 1790D-T16BV0 Universal dc Input Base Block Attribute Value Inputs per Base Block 16 point, sinking or sourcing On-state Voltage 9.6V dc min, 24V dc nom, 28.8V dc max Off-state Voltage 5.0V dc max On-state Current 8 mA max per channel @ 28.8V dc Input Impedance, Nom 4.8 kΩ Field Power Dissipation 3.68 W max @ 28.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O 1790D-T8BV8V, 1790D-T8BV8B dc Input/Output Combination Base Block Attribute Value Field Power Dissipation 3.22 W @ 28.8V dc Isolation Voltage 50V dc (continuous), reinforced insulation type, tested at 1250V ac for 60 s, I/O to system Input Inputs per Base Block 8 points non-isolated, sinking or sourcing On-state Voltage 9.6V dc min 24V dc nom 28.8V dc max Off-state Voltage, Max 5.0V dc On-state Current 8 mA max per channel @ 28.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O 21 1790D-TOW6 ac/dc Relay Output Base Block Attribute Value Relay Type Form A, normally open Single pole, single throw Output Voltage Range (load dependent) 5…28V dc @ 2.0 A resistive 48V dc @ 0.8 A resistive 125V ac @ 2.0 A resistive 250V ac @ 2.0 A resistive Load, Min 100 µA, 100 mV dc per point On-state Voltage Drop, Max 0.5V @ 2.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O 1790D-T8AO ac Input Base Block Attribute Value Off-state Current 45V ac max Input Signal Delay, Off to On 10 ms Input Signal Delay, On to Off 30 ms max Field Power Dissipation 3VA @ 132V ac Isolation Voltage 120V ac (continuous), reinforced insulation type, tested at 1250V ac for 60 s, I/O to system 1790D-TOA6 Output Base Block Attribute Value Outputs per Expansion Block 6 points non-isolated Load Voltage Range 15…132V ac Load C
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O 23 1790D-TOA6 Output Base Block Input Signal Delay, On to Off 30 ms max Field Power Dissipation 3.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O Environmental - Common To All Base Blocks in This Publication EFT/B Immunity IEC 61000-4-4 ±1 kV at 5 kHz on power ports ±2 kV at 5 kHz on signal ports ±2 kV at 5 kHz on communications ports Surge Transient Immunity IEC 61000-4-5: ±1 kV line-line (DM) on power ports ±1 kV line-line (DM) on signal ports ±2 kV line-earth (CM) on communications ports Conducted RF Immunity IEC61000-4-6 10V rms with 1 kHz sine-wave 80%AM at 150 kHz...
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O 25 Environmental - Common To All Base Blocks in This Publication DeviceNet Power Dissipation 1.2 W max @ 28.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O Certifications Attribute Certification(1) (when product is marked) Value 1790D-TOV16, 1790D-TOB16, 1790D-T8BV8V, 1790D-T8BV8B, 1790D-T16BV0 c-UL-us UL Listed Industrial Control Equipment, certified for U.S. and Canada. See UL File E65584. c-UL-us UL Listed for Class I, Division 2, Group A,B,C,D Hazardous Locations, certified for U.S. and Canada. See UL File E194810.
DeviceNet Digital Base Terminal Block CompactBlock LDX I/O 27 Notes: Publication 1790-IN006C-EN-P - May 2006
