3. Insert the end of the cable having the RJ45 network connector into
the ControlNet network access port (NAP) of a ControlNet
network-enabled device.
Traffic Analyzer Software
The 1784-U2CN cable is designed to work with Frontline’s NetDecoder
traffic analyzer software. For more information on Frontline’s product, go to
either http://www.rockwellautomation.com/encompass/ or
http://www.fte.com.
USB Cable
RJ45 ControlNet Network Connector
