Installation Instructions User guide

4 USB-to-ControlNet Cable
Publication
1784-IN047A-EN-P - November 2008
About the Cable
The 1784-U2CN USB-to-ControlNet cable lets you connect a notebook or
desktop computer to a ControlNet network by using an unused USB port on
the computer. The product replaces the 1784-PCC communication card for
computers that do not have PCMCIA slots.
IMPORTANT
To comply with the CE Low Voltage Directive (LVD), this equipment must be
powered from a source compliant with Safety Extra Low Voltage (SELV) or
Protected Extra Low Voltage (PELV).
USB Cable
Status Indicators
RJ45 ControlNet Network Connector
Node Address Switches
