Installation Instructions User guide

USB-to-ControlNet Cable 11
Publication
1784-IN047A-EN-P - November 2008
Specifications
USB-to-ControlNet Cable, Catalog Number 1784-U2CN
Attribute Value
Enclosure type rating Meets IP30
Power dissipation, max 0.5 W
Supply voltage 5.00V DC
5.25V DC max
Supply current 75 mA
Power consumption, max 0.5 W
Isolation voltage 30V continuous, Basic Insulation Type
Type tested at 500V AC for 60 s, ControlNet to USB
Wiring category
(1)
(1)
Use this Conductor Category information for planning conductor routing. Refer to Industrial
Automation Wiring and Grounding Guidelines, publication 1770-4.1
.
2 - on communication ports
ControlNet current value 70 mA @ 24V
