Module Status (MS) Green The cable is operating normally.
Off No power to the cable.
Flashing green The cable is operating in a normal condition
and is online with no connections established.
• The cable may be in Standby mode.
• The cable needs commissioning due to
missing, incomplete, or incorrect
configuration.
Flashing red The cable has a recoverable fault.
Red The cable has an unrecoverable fault and may
need to be replaced.
Flashing
red/green
The cable is performing a self-test.
ControlNet Network
Status (NS)
Off Not on network.
Red Network interface faulted.
Flashing
red/green
Invalid network configuration (for example, a
MAC ID above UMAX).
Flashing red • Duplicate node detected.
• Link fault.
• No MAC frames received.
Flashing green • Temporary channel error.
• Listen only.
Green Normal operation. MAC frame received
without error.
Indicator Status Description
