Installation Instructions USB-to-ControlNet Cable Catalog Number 1784-U2CN Topic Page Important User Information 2 Environment and Enclosure 3 About the Cable 4 Install the Cable 5 Status Indicators 9 Specifications 11 Additional Resources 14
USB-to-ControlNet Cable Important User Information Solid state equipment has operational characteristics differing from those of electromechanical equipment. Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls (publication SGI-1.1 available from your local Rockwell Automation sales office or online at http://literature.rockwellautomation.com) describes some important differences between solid state equipment and hard-wired electromechanical devices.
USB-to-ControlNet Cable 3 Environment and Enclosure ATTENTION This equipment is intended for use in overvoltage Category II applications (as defined in IEC publication 60664-1), at altitudes up to 2000 m (6562 ft) without derating. This equipment is considered Group 1, Class A industrial equipment according to IEC/CISPR Publication 11.
USB-to-ControlNet Cable About the Cable The 1784-U2CN USB-to-ControlNet cable lets you connect a notebook or desktop computer to a ControlNet network by using an unused USB port on the computer. The product replaces the 1784-PCC communication card for computers that do not have PCMCIA slots. IMPORTANT To comply with the CE Low Voltage Directive (LVD), this equipment must be powered from a source compliant with Safety Extra Low Voltage (SELV) or Protected Extra Low Voltage (PELV).
USB-to-ControlNet Cable 5 Install the Cable Follow these procedures to install the cable. ATTENTION This equipment is sensitive to electrostatic discharge, which can cause internal damage and affect normal operation. Follow these guidelines when you handle this equipment: • Touch a grounded object to discharge potential static. • Do not touch connectors or pins. • Store the equipment in appropriate static-safe packaging when not in use.
USB-to-ControlNet Cable Configure and Connect the Cable ATTENTION USB and ControlNet connection lengths must be less than 3 meters. Do not attempt to extend the cables. 1. Use the rotary switches to set the module node address to a valid number (1…99). Node Address (Rotary) Switches 2. Insert the end of the cable having the USB connector into a USB port on a computer.
USB-to-ControlNet Cable 7 3. Insert the end of the cable having the RJ45 network connector into the ControlNet network access port (NAP) of a ControlNet network-enabled device. RJ45 ControlNet Network Connector USB Cable Traffic Analyzer Software The 1784-U2CN cable is designed to work with Frontline’s NetDecoder traffic analyzer software. For more information on Frontline’s product, go to either http://www.rockwellautomation.com/encompass/ or http://www.fte.com.
USB-to-ControlNet Cable Product Dimensions The following illustration shows the product dimensions. Enclosure Length: 7.62 cm (3 in.) Width: 5.08 cm (2 in.) Thickness: 2.54 cm (1 in.) USB Cable Length 0.61 m (2 ft) Publication 1784-IN047A-EN-P - November 2008 ControlNet NAP Cable Length 3.
USB-to-ControlNet Cable 9 Status Indicators The following table describes the cable status indicators. Module Status USB ControlNet Network Status Indicator Status Description USB Green The cable is configured, but no network traffic is present. Flashing green Network traffic is present. Off Unable to transfer data. • Disconnected from host.
USB-to-ControlNet Cable Indicator Status Description Module Status (MS) Green The cable is operating normally. Off No power to the cable. Flashing green The cable is operating in a normal condition and is online with no connections established. • The cable may be in Standby mode. • The cable needs commissioning due to missing, incomplete, or incorrect configuration. ControlNet Network Status (NS) Flashing red The cable has a recoverable fault.
USB-to-ControlNet Cable 11 Specifications USB-to-ControlNet Cable, Catalog Number 1784-U2CN Attribute Value Enclosure type rating Meets IP30 Power dissipation, max 0.5 W Supply voltage 5.00V DC 5.25V DC max Supply current 75 mA Power consumption, max 0.
USB-to-ControlNet Cable Environmental Specifications Attribute Value Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold), IEC 60068-2-2 (Test Bd, Operating Dry Heat), IEC 60068-2-14 (Test Nb, Operating Thermal Shock): 0…55 °C (32…131 °F) Temperature, nonoperating IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold), IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat), IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock): -10…85 °C (14…185 °F) Relative humidity IEC 600
USB-to-ControlNet Cable 13 Certifications Certifications (when product is Value marked)(1) c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada. See UL File E65584. CE European Union 2004/108/EC EMC Directive, compliant with: EN 61326-1; Meas./Control/Lab.
USB-to-ControlNet Cable Additional Resources These documents contain additional information concerning related Rockwell Automation products. Resource Description ControlNet Coax Media Planning and Installation Guide, publication CNET-IN002. Provides ControlNet network planning information. Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1 Provides general guidelines for installing a Rockwell Automation industrial system. Product Certifications website, http://www.ab.
