Starting Your Processor
Chapter 5
5-6
Using 8-Point I/O Modules
I/O modules generally provide eight input terminals or eight output
terminals. Figure 5.4 illustrates the 2-slot I/O group concept with two
8-point input modules. Figure 5.5 illustrates the 2-slot I/O group concept
with an 8-point input and an 8-point output module.
Figure 5.4
Illustration
of 2Slot Addressing with Two 8Point Input Modules
00
01
02
03
04
05
06
07
10
11
12
13
14
15
16
17
17 161514 12 10070605 03020100041113
17 161514 12 10070605 03020100041113
11867
unused
Output image table word
corresponding to the I/O group
Input image table word
corresponding to the I/O group
input
terminals
2slot
I/O group
input
terminals
