Address Delimiters
Delimiter Format Explanation Message Report Format
*XXX* Enter 3digit word address between delimiters. Displays the 3digit BCD value at assigned
word address.
*XXX1*
or
*XXX0*
Enter 3digit word address and a 1" for upper byte or a
0" for lower byte between delimiters.
Displays the 3digit octal value at assigned
byte address.
*XXXXX* Enter 5digit bit address between delimiters. Displays the On or Off status of the assigned bit
address.
#XXX# Enter 3, 4, or 5digit word address between delimiters. Displays the 3digit BCD value at assigned
word address.
!XXX! Enter 3, 4, or 5digit word address between delimiters. Displays the 4digit hex value at address.
&XXX1&
&XXX0&
Enter 3, 4, or 5 digit word address and a 1"for upper
byte or a 0" for lower byte between delimiters.
Displays the 3digit octal value at the assigned
byte address.
XXXXX Enter 5, 6, or 7digit bit address between delimiters. Displays the On or Off status of the assigned bit
address.
Report Generation Commands
Command Key Sequence Description
Enter report generation
function
[RECORD][DISPLAY]
Set baud rate
(Message Code Keys)
Puts industrial terminal into report
generation function.
Same (entered from a peripheral device).
Message store [M][S][,]
(Message Number)
[RETURN]
Stores message in processor memory. Use [ESC]
to end message.
Message print [M][P][,]
(Message Number)
[RETURN]
Prints message exactly as entered.
Message report [M][R][,]
(Message Number)
[RETURN]
Prints message with current data table values or
bit status.
Message delete [M][D][,]
(Message Number)
[RETURN]
Removes message from processor memory.
Message index [M][I][RETURN] Lists messages used and the number of words in
each message.
Automatic report
generation.
[SEARCH][4][0]
[M][R][RETURN]
Allows messages to be printed through
program control.
Exit automatic report
generation
[ESC]
[CANCEL COMMAND]
1
Terminates automatic report generation.
Exit report
[ESC]
[CANCEL COMMAND]
1
Returns to ladder diagram display.
Terminates Report Generation Function.
[CANCEL COMMAND] can only be used if the function was entered by a command from a peripheral device.
1
