Quick Reference
Appendix E
E-27
Table 1.B
W
ords 10 through 24
Independent Gain
Equation
Dependent Gain
Equation
Range
00009999
Word 10
Zero Crossing Dead Band
Range
00009999
Units
00009999
Range
0000100%
Units
Percent
Range
0000100%
Unites
Percent
Word 11
Set Output Value
Word 12
Maximum Control Output
Range
0000100%
Units
Percent
Range
0000100%
Units
Percent
Range
0000100%
Units
Percent
Word 13
Minimum Control Output
Range
0000100%
Units
Percent
Range
000099.99
Units
sec
Word 14
Loop Update Time
Range
00.0099.99
Units
sec
Range
00009999
Word 15
Process Variable - PV
Range
00009999
Range
00009999
Word 16
Error
2
Range
00009999
Range
0000100%
Units
Percent
Word 17
Control Output
2
Range
0000100%
Units
Percent
Words 18 through 24
Reserved
3
Do not change while processor is operating.
Do not change. These values are set by the PID function
.
Do not change Reserved bits.
1
2
3
