Quick Reference
Appendix E
E-19
Help
Directories
Function Key Sequence Mode Description
Help directory [HELP] Any Displays a list of the keys that are used with the
[HELP] key to obtain further directories.
Control function directory [SEARCH]
[HELP]
Any Provides a list of all control functions that use
the [SEARCH] key.
Record function directory [RECORD]
[HELP]
Any Provides a list of functions that use the
[RECORD] KEY.
Clear memory directory [CLEAR MEMORY]
[HELP]
Remote Prog Provides a list of all functions that use the
[CLEAR MEMORY] key.
Data monitor directory [DISPLAY]
[HELP]
Any Provides the choice of data monitor display
accessed by the [DISPLAY] key.
File instruction directory [FILE] [HELP] Any Provides a list of all instructions that use the
[FILE] key.
Sequencer instruction directory [SEQ][HELP] Any Provides a list of all instructions that use the
[SEQ] key.
Block transfer directory [BLOCK XFER]
[HELP]
Any Provides a list of all instructions that use the
[BLOCK XFER] key.
All directories [CANCEL COMMAND] Any To terminate.
Help
