Key Sequence
1770T3 Display Instruction Notes
FILE
10
EN
FILE TO FILE MOVE
COUNTER ADDR:
POSITION:
FILE LENGTH:
030
001
003
FILE A:
FILE B:
RATE PER SCAN:
200- 202
300- 302
003
DN
030
17
030
15
Output instruction.
Modes: Complete, Distributed, and Incremental Counter
is internally incremented by the instruction.
Requires 5 words of user program.
FILE
11
DN
WORD TO FILE MOVE
COUNTER ADDR:
POSITION:
FILE LENGTH:
WORD ADDR:
FILE R:
001
003
010
110- 112
030
030
15
Output instruction.
Counter must be externally indexed by user program.
Data is transferred every scan that rung is true.
Requires 4 words of user program.
FILE
12
DN
FILE TO WORD MOVE
COUNTER ADDR:
POSITION:
FILE LENGTH:
FILE A:
WORD ADDR:
001
003
200- 202
010
030
030
15
Same as WordToFile.
Important: Numbers shown are default values. The number of default address digits displayed (3 or 4) will depend on the size of
the data table.
Here is an explanation of each value:
This Value: Stores This:
Counter address Address of the instruction's file position in the accumulated
value area of the data table.
Position Current word being operated upon (accumulated value of
the counter).
File length Number of words in file (preset value of the counter).
File A Starting address of the source file.
File R Starting address of the destination file.
Word address Address of the source word or destination word outside of
the file.
Rate per scan Number of words of data moved per scan.
Data Transfer File Instructions
