Program Troubleshooting
Chapter 26
26-8
Second Method (Entering from the Remote Program or Program mode)
1. Cursor to the first rung of the main program to be made inactive.
2. Position the cursor on the first instruction in the rung.
3. Press [Insert] [←] [T. End].
Removing
a T
emporary End Instruction
Remove a Temporary End instruction by performing the following steps.
1. Position the cursor on the Temporary End instruction you are going
to remove.
2. Press [Remove] [T. End].
Entering a Rung After a T
emporary End Instruction
Enter a rung after a Temporary End instruction by performing the
following steps.
1. Place the cursor on the Temporary End instruction.
2. Press [Rung].
3. Enter the new rung.
The industrial terminal prevents you from using the Temporary End
instruction in any of the following ways, which would result in a run
time error.
Using more than one Temporary End instruction at a time.
Using the Temporary End instruction in the subroutine area.
Inserting or removing the instruction during online programming.
Placing the instruction in the path of Jump or Jump To
Subroutine instructions.
