Chapter
4
4-1
Installing Your Programmable Controller
This chapter discusses the location and methods of installing your
processor. When you have finished, you should be able to:
determine where to locate your processor system
install your processor system
Table 4.A lists the hardware needed to install your processor system.
Table 4.A
Hardware for Y our Processor System
AllenBradley Hardware Catalog Number
I/O chassis 1771A1B, A2B, A3B, A3B1, A4B
I/O modules 1771 product line
Industrial terminal 1770T3 series C
Power supplies 1771P3, P4, P5, P7
Emergency stop 800 product line switches
Master control relay 700 product line
Disconnects 1494 product line
Suppression devices 599K04, 700N24, 1401N10
The quantity of the hardware you need depends on your application.
Consult your local Allen-Bradley sales engineer or distributor for more
information concerning these items.
In addition to our hardware, we recommend:
a metal enclosure to protect your processor from electromagnetic
interference (EMI) noise and airborne contaminants
enclosure backpanel
power supplies for I/O devices
6.35 mm (0.25 inch) bolts
power cable for ac input power
electrical tape or shrink tubing
tie wraps for wires
Chapter Objectives
Related Hardware
