Report Generation
Chapter 23
23-6
The words END OF MESSAGE STORE appear on the screen.
Returns the display to the ladder diagram.
Message Print - MP
Accessible in any mode, the message print command is to print the
contents of a message to verify it. You can print a message with the
following keystrokes:
You must be in report generation.
MP,n appears on the screen.
n = message number
Message n appears on the screen.
Returns the display to the ladder diagram.
The message print command is valid for message 0. It prints out message
control word addresses in a form similar to that shown in table 23.A. If the
location of the message control file is to be changed or you no longer need
message 0, it can be deleted with the message delete command and
re-entered at any time.
In the example, the message print command would give the following:
You must be in report generation.
MP,n appears on the screen.
SR6 IS *01305* IN CYCLE #030#
Returns the display to the ladder diagram.
