Chapter
23
23-1
Report Generation
This chapter describes how to generate messages containing:
ASCII characters
graphic characters
variable information
You can use the report generation function of the 1770-T3 industrial
terminal to generate messages that contain ASCII and graphic characters,
and variable data table information. The industrial terminal must be in the
Mini-PLC-2/02, Mini-PLC-2/16, or Mini-PLC-2/17 mode. Messages are
stored in the processor’s memory after the END of program statement.
The 1770-T3 industrial terminal report generation features include:
as many as 70 messages - you can choose the number of messages to
be stored.
simple programming - only 20 or 3 rungs of programming are required
to display a message by program logic
selectable communication rates - you can choose from seven
communication rates: 110, 300, 600, 1200, 2400, 4800 or 9600 bits
per second
selectable parity bit - you can choose odd, even or no parity
Chapter Objectives
