Sequencer
Chapter 21
21-13
BINARY DATA MONITOR
SEQUENCER OUTPUT
COUNTER ADDR: 200
STEP: 001 SEQUENCER LENGTH: 006
FILE: 400- 413
OUTPUT ADDR: 110
201
DATA:
00000000 00000000
00000000 00000000
MASK ADDR: 070
071
00000000 00000000
STEP WORD 1
WORD 2
00000000 00000000
00000000 00000000
00000000 00000000
00000000 00000000
00000000 00000000
00000000 00000000
00000010 00000000
00000010 00000001
00000010 00010001
001
002
003
004
005
006
DAT
A: 00000010 01010001
00000010 00010001
00000010 01000001
00000010 00000000
SHIFT
To display your rung.
DATA:
00000010 01010001
CANCEL
COMMAND
The Sequencer Output instruction transfers the values of the current
sequencer step to a specified output word. Here are some characteristics of
the sequencer output instruction.
You can transfer up to 64 bits.
This instruction is programmed as an output instruction (can be
programmed in the same rung as a sequencer input instruction).
You can mask the unused output bits.
The counter is internally indexed by the instruction (external counter
instruction is not required).
The instruction requires 5-8 words of your program.
If the rung condition becomes:
True The counter increments to the next step and transfers
the data.
False No action is taken.
Sequencer Output
