DISPLAY
Sequencer
Chapter 21
21-11
BINARY DATA MONITOR
SEQUENCER OUTPUT
COUNTER ADDR: 200
STEP: 001 SEQUENCER LENGTH: 006
FILE: 600- 613
OUTPUT ADDR: 012
013
DATA:
00000000 00000000
00000000 00000000
MASK ADDR: 075
076
DATA:
00000000 00000000
00000000 00000000
STEP WORD 1
WORD 2
00000000
00000000
00000000 00000000
00000000 00000000
00000000 00000000
00000000 00000000
00000000 00000000
00000010 00000000
00000010 00000001
00000000 00000000
00000000 00000000
00000000 00000000
00000000 00000000
001
002
003
004
005
006
DAT
A: 00000010 00000001
INSERT
↓↓
Cursor down one line.
The cursor is on the last digit of the third word of DATA in the command
buffer. The digits in step 3 for word 3 are intensified.
Continue inserting your data.
003: 00000010 00010001
004: 00000010 00010001
005: 00000010 01000001
006: 00000010 00000000
To add data to WORD 2 press [Shift] [→] and cursor up or down
as needed.
Do not press [Cancel Command]. We will use the display to add a mask.
The word DISPLAY appears in the lower left hand corner of the screen.
