Data Transfer File Instruction
Chapter 19
19-12
We will change the data in the command buffer from 0162 to 0281.
0281
HEXDECIMAL DATA MONITOR
FILE TO FILE MOVE
POSITION: 001
COUNTER ADDR:
FILE A:
200
400406
FILE LENGTH:
FILE R:
007
500 506
POSITION FILE A DATA FILE R DATA
001
002
003
004
005
006
007
1257
0721
0879
0162
1982
9715
5761
1257
0721
0879
0162
1982
9715
5761
DATA: 0281
HEXDECIMAL DATA MONITOR
FILE TO FILE MOVE
POSITION: 001
COUNTER ADDR:
FILE A:
200
400406
FILE LENGTH:
FILE R:
007
500 506
POSITION FILE A DATA FILE R DATA
001
002
003
004
005
006
007
1257
0721
0879
0162
1982
9715
5761
1257
0721
0879
0162
1982
9715
5761
DATA: 0281
INSERT
Notice that file R’s DATA has not changed.
Now practice by changing POSITION 006 of file A to 7777.
Important: If you wanted to change the data in FILE R, follow the same
procedure. To move your cursor over to file R, press [Insert] [→]. Then,
follow the same procedure.
