Data Transfer File Instuction
Chapter 19
19-11
Editing in a Completed Rung
Edit a File-to-File Move instruction by performing the following steps in
the hexadecimal data monitor display.
The FILE TO FILE MOVE instruction rung is displayed.
The word SEARCH appears in the lower left corner of the industrial
terminal screen.
Puts the processor in the run/program mode.
The word DISPLAY appears in the lower left corner of the industrial
terminal screen.
1
HEXDECIMAL DATA MONITOR
FILE TO FILE MOVE
POSITION: 001
COUNTER ADDR:
FILE A:
200
400406
FILE LENGTH:
FILE R:
007
500 506
POSITION FILE A DATA FILE R DATA
001
002
003
004
005
006
007
1257
0721
0879
0162
1982
9715
5761
1257
0721
0879
0162
1982
9715
5761
DATA: 1257
Notice the command buffer at the bottom of the screen. It is labeled
DATA: 1257. This is also the same number in FILE A at POSITION 001.
Cursor down to POSITION 004.
