Data Transfer File Instuction
Chapter 19
19-9
Important: If you made a mistake, you can correct it by moving the
cursor left or right to the incorrect number and then pressing the correct
number key.
HEXDECIMAL DATA MONITOR
FILE TO FILE MOVE
POSITION: 001
COUNTER ADDR:
FILE A:
200
400406
FILE LENGTH:
FILE R:
007
500 506
POSITION FILE A DATA FILE R DATA
001
002
003
004
005
006
007
1257
0000
0000
0000
0000
0000
0000
0000
0000
0000
0000
0000
0000
0000
DATA: 1257
INSERT
This information (1257) now appears in position 001 of file A. The
command buffer at the bottom of the screen still displays 1257.
↓↓
Cursor down one line.
We will now add information to position 002.
HEXDECIMAL DATA MONITOR
FILE TO FILE MOVE
POSITION: 001
COUNTER ADDR:
FILE A:
200
400406
FILE LENGTH:
FILE R:
007
500 506
POSITION FILE A DATA FILE R DATA
001
002
003
004
005
006
007
1257
0000
0000
0000
0000
0000
0000
0000
0000
0000
0000
0000
0000
0000
DATA: 0721
0721
HEXDECIMAL DATA MONITOR
FILE TO FILE MOVE
POSITION: 001
COUNTER ADDR:
FILE A:
200
400406
FILE LENGTH:
FILE R:
007
500 506
POSITION FILE A DATA FILE R DATA
001
002
003
004
005
006
007
1257
0721
0000
0000
0000
0000
0000
0000
0000
0000
0000
0000
0000
0000
DATA: 0721
INSERT
