EAF
Process Control Instructions
Chapter 16
16-28
Feedforward or Bias (Word 07)
This input is added to the calculated control output of the PID equation. It
is used when a bias is needed or if feedforward control is desired. This
value can be a storage constant or a calculated variable of
process measurement.
Proportional only control will give a steady-state offset of the process
variable from setpoint. A bias value can be added into the control output
using this word to bring the process variable to the set point.
The feedforward value (Figure 16.9) represents a measured feed system
disturbance fed into the PID equation. Its effect is to adjust the output
before the disturbance has a chance to change the process variable, thereby
reducing the impact of the disturbance on the system.
Figure 16.9
This
Is an Example of Feedforward Control
PID
Equation
Flow
P
V
Level
Detector
CO
Σ
SP
Σ
FT
Transmitter
10374-I
Feedforward/Bias Sign Bit (Word 02, Bit 02)
Set/reset this bit to change the sign of the feedforward value.
Reset (0) value is positive
Set (1) value is negative
