0.866025 for the sine function and and 0.500 for the cosine function.
Figure 15.7 shows how it is stored in the data table.
Figure 15.7
EAF
Sine Function Format After Execution
17 16 15 14 10 7 4 3
Data
0
Result
Address
060
061
062
063
10366-I
13
XS
Address
040
041
042
043
000
0
0
0
000
0
6
000
000
8
2
00
O
66
50
Operand
Result
The FIFO Load and FIFO Unload are output instructions that can be used
together to construct an asynchronous word shift register. Length of the
FIFO can be a maximum 999 words long.
Upon a false-to-true transition of the FIFO Load rung, the contents of
the Input Word is transferred into the File as long as the input word is
non-zero.
Upon a false-to-true transition of the FIFO Unload rung, the word at the
top of the file (highest file address) is transferred out of the File to an
Output Word.
Important: Only non-zero values can be loaded.
Use the full and empty flags in your ladder program to assure that the data
being loaded/unloaded to/from the file is not lost or invalid.
FIFO Load and FIFO Unload
