Chapter
15
15-1
EAF Logarithmic, Trigonometric, and
FIFO Instructions
This chapter describes the Logarithmic, Trigonometric, and FIFO Load,
and FIFO Unload EAF instructions.
Table 15.A
EAF Function Numbers
If you want to perform
an operation of this type
Use this
function number
The MiniPLC2/02, MiniPLC2/16 and MiniPLC2/17 can perform
these functions
FIFO Load
FIFO Unload
Log
10
Sin x
Cos x
(28)
(29)
(30)
(35)
(36)
The MiniPLC2/17 can perform these additional functions.
Log
e
(31)
When a processor executes an EAF, it uses the data table format shown in
Figure 15.1. The Operand represents the number you manipulate.
Chapter Objectives
One Operand EAFs
