Memory Organization
Chapter 7
7-9
Three things happen to the display.
The cursor returns to the NUMBER OF 128–WORD D.T. BLOCKS.
NUMBER OF T/C changes to 022.
DATA TABLE SIZE becomes 92.
To expand your data table to any size between 130 and 256 words, do this:
02 DA T A TABLE CONFIGURA TION
NUMBER OF 128-WORD D. T . BLOCKS 01
NUMBER OF INPUT/OUTPUT RACKS 2
NUMBER OF T/C (if available) 104
DAT A T ABLE SIZE 0258
Three things happen to the data table configuration:
The cursor jumps to the Number of T/C.
Number of T/C changes to 104.
Data table size becomes 256.
Enter the number of timer/counters equivalent to the desired size of the
data table (Table 7.A).
065 DA T A TABLE CONFIGURA TION
NUMBER OF 128-WORD D. T . BLOCKS 021
NUMBER OF INPUT/OUTPUT RACKS 2
NUMBER OF T/C (if available) 165
DAT A T ABLE SIZE 0178
Three things happen to the data table configuration:
The cursor returns to the NUMBER OF 128–WORD D.T. BLOCKS.
NUMBER OF T/C changes to 065.
DATA TABLE SIZE becomes 178.
If you want to increase the data table size to 256 words, press 02 and then
CANCEL COMMAND.
If you want to increase the data table size beyond 256 words, remember
the data table increases in steps of 128 words. See Table 7.B.
Expanding the Data Table
Between 130 and 256 Words
