2–32 Command Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Ejector Full Advance Profile Setpoints
Word Description
EPC09 Full Advance Segment 1 Velocity Setpoint [09] or [10]
if: then the module:
you select Vel/Pos profile execution controls ejector advance speed to this setpoint after starting any full advance portion of
the Ejector Profile until ejector position reaches the smaller of non-zero EPC11 or
EPC59
EPC03-B14 is RESET reads this parameter in percent velocity
EPC03-B14 is SET reads it in in.(mm)/s.
EPC10 Full Advance Segment 1 Pressure Setpoint [03]
if: then the module:
you select Press/Pos profile execution controls ejector advance pressure to this setpoint after starting any full advance portion
of the Ejector Profile until ejector position reaches the smaller of non-zero EPC11 or
EPC59
EPC11 End of Full Advance Segment 1 Position Setpoint [16]
EPC12 Full Advance Segment 2 Velocity Setpoint [09] or [10]
if: then the module:
you select Vel/Pos profile execution controls ejector advance speed to this setpoint during any full advance portion of the
Ejector Profile from the ejector position EPC11until ejector position reaches the smaller
of non-zero EPC14 or EPC59
EPC03-B14 is RESET reads this parameter in percent velocity
EPC03-B14 is SET reads it in in.(mm)/s
EPC13 Full Advance Segment 2 Pressure Setpoint [03]
if: then the module:
you select Press/Pos profile execution controls ejector advance pressure to this setpoint after during any full advance portion
of the Ejector Profile from the ejector position EPC11 until ejector position reaches
the smaller of non-zero EPC14 or EPC59
EPC14 End of Full Advance Segment 2 Position Setpoint [16]
EPC15 Full Advance Segment 3 Velocity Setpoint [09] or [10]
if: then the module:
you select Vel/Pos profile execution controls ejector advance speed to this setpoint during any full advance portion of the
Ejector Profile from the ejector position EPC14 until ejector position reaches EPC59
EPC03-B14 is RESET reads this parameter in percent velocity
EPC03-B14 is SET reads it in in.(mm)/s
EPC16 Full Advance Segment 3 Pressure Setpoint [03]
if: then the module:
you select Press/Pos profile execution controls ejector advance pressure to this setpoint during any full advance portion of the
Ejector Profile from the ejector position EPC14 until ejector position reaches EPC59
EPC17 - 20 Reserved
Ejector Tip Retract Profile Setpoints
Word Description
EPC21 Tip Retract Velocity Setpoint [09] or [10]
if: then the module:
you select Vel/Pos controls ejector retract speed to this setpoint after starting any tip retract portion of the Ejector
profile execution Profile until ejector position reaches the larger of EPC23 or EPC60
EPC03-B14 is RESET reads this parameter in percent velocity
EPC03-B14 is SET reads it in in.(mm)/s
EPC22 Tip Retract Pressure Setpoint [03]
if: then the module:
you select Press/Pos controls ejector retract pressure to this setpoint after starting any tip retract portion of the Ejector
profile execution Profile until ejector position reaches the larger of EPC23 or EPC60
