Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word DescriptionBit
DYC05
B06 = 0 Normal
= 1 Re-initialize Hold Profile ERC Values
A false-to-true transition of this bit forces the module to re-initialize the five ERC values associated with the Hold Profile.
B07 = 0 Normal
= 1 Open
B08 = 0 Normal
= 1 Re-initialize Plastication Profile ERC Values
A false-to-true transition of this bit forces module to re-initialize the 11 ERC values associated with Plastication Profile.
B09 = 0 Normal
= 1 Open
B10 = 0 Normal
= 1 Re-initialize First Clamp Open Profile ERC Values
A false-to-true transition of this bit forces the module to re-initialize the three ERC values associated with the First
Clamp Open Profile.
B11 = 0 Normal
= 1 Re-initialize Second Clamp Open Profile ERC Values
A false-to-true transition of this bit forces the module to re-initialize the three ERC values associated with the Second
Clamp Open Profile.
B12 = 0 Normal
= 1 Re-initialize Third Clamp Open Profile ERC Values
A false-to-true transition of this bit forces the module to re-initialize the three ERC values associated with the Third
Clamp Open Profile.
B13 = 0 Normal
= 1 Re-initialize Clamp Open Slow Profile ERC Values
A false-to-true transition of this bit forces the module to re-initialize the two ERC values associated with the Clamp
Open Slow Profile.
B14 = 0 Normal
= 1 Re-initialize Ejector Profile ERC Values
A false-to-true transition of this bit forces module to re-initialize the eight ERC values associated with the Ejector Profile.
B15 = 0 Normal
= 1 Re-initialize All ERC Values
A false-to-true transition of this bit forces the module to re-initialize the 62 ERC values associated with all profiles.
DYC06 Open
DYC07 Process Trace Commands
B00 Process trace data collection inhibited (examined at beginning of injection phase)
B01 Return injection position trace data in next PTS block
B02 Return trace #1 data in next PTS block
B03 Return trace #2 data in next PTS block
B04 Return trace #3 data in next PTS block
B05 Return trace #4 data in next PTS block
B06
-B14
Open
B15 Return phase/segment start information in next PTS block
DYC08 Process Trace Data Block Request
B00 Return trace data points 1 to 50 in next PTS block
B01 Return trace data points 51 to 100 in next PTS block
B02 Return trace data points 101 to 150 in next PTS block
B03 Return trace data points 151 to 200 in next PTS block
B04 Return trace data points 201 to 250 in next PTS block
B05 Return trace data points 251 to 300 in next PTS block
B06 Return trace data points 301 to 350 in next PTS block
B07 Return trace data points 351 to 400 in next PTS block
B08
-B15
Open
