2–18 Command Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word
Bit Description
DYC02 B08 = 0 Normal
= 1 Execute Plastication Profile
A false-to-true transition of this bit forces the module to do
one
of the following, attempted in the order listed.
if: then the module:
any of SYS07-B00 through B05 are SET ignores any profile commands
SYS15-B14 is RESET latches SYS13-B09
all of the following are true:
– ram (screw) position equals or exceeds sum of PPC61 + PPC62
– PPC03-B08 is RESET
– SYS15-B15 is RESET
latches SYS13-B10
ram (screw) position is less than the sum of PPC61 + PPC62 terminates any action in progress and
starts the Plastication Profile
both of the following are true:
– ram (screw) position equals or exceeds sum of PPC61 + PPC62
– PPC03-B08 is SET
terminates any action in progress and
sets outputs to PLC33 - PLC40
all of the following are true:
– ram (screw) position equals or exceeds sum of PPC61 + PPC62
– PPC03-B08 is SET
– PSC05 is not zero
terminates any action in progress and
starts Post-decompression Movement
all of the following are true:
– ram (screw) position equals or exceeds sum of PPC61 + PPC62
– PPC03-B08 is SET
– PSC05 is zero
terminates any action in progress and
sets outputs to PSC33 - PSC40
B09 = 0 Normal
= 1 Execute Post-decompression Movement
A false-to-true transition of this bit forces the module to do
one
of the following, attempted in the order listed.
if: then the module:
any of SYS07-B00 through B05 are SET ignores any movement commands
SYS15-B15 is RESET latches SYS13-B10
PSC05 is not zero terminates any action in progress and
starts Post-decompression Movement
PSC05 is zero terminates any action in progress and
sets outputs to PSC33 - PSC40
B10
Clamp Open Profiles Execution Commands
Bits DYC02-B10 - DYC02-B14 are the five
action execution
commands available to initiate all profiled Clamp Open and
Ejector movements. The four Clamp Open Profiles and the Ejector Profiles may be logically linked as a single
integrated machine movement if all three Clamp Open Profiles Logical Bridge Bits and the single Ejector Profile
Logical Bridge Bit are RESET. The four Logical Bridge Bits are:
OPC03-B08 - Link First Open and Second Open
OPC03-B09 - Link Second Open and Third Open
OPC03-B10 - Link Third Open and Open Slow
EPC03-B08 - Start Ejectors on Position.
If all four bits are RESET, transmit only DYC02-B12 to the module to force the entire Clamp Open and Eject portion of
an automatic machine cycle.
B10
= 0 Normal
= 1 Execute First Clamp Open Profile
A false-to-true transition of this bit forces the module to do
one
of the following, attempted in the order listed.
if: then the module:
any of SYS07-B00 through B05 are SET ignores any profile commands
either of the following are true:
– OPC03-B08 is SET and SYS16-B00 is RESET
– SYS16-B04 is RESET
latches SYS13-B11
