User Manual

2–10 Command Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
First Clamp Close Profile Setpoints
Word Description
CPC09 Segment 1 Velocity Setpoint [07] or [08]
if: then the module:
you select Vel/Pos profile execution controls clamp close speed to this setpoint after starting the First Clamp Close Profile
until clamp position reaches the larger of CPC11 or CPC61
CPC03-B14 is RESET reads this parameter in percent velocity
CPC03-B14 is SET reads it in in.(mm)/s
CPC10 Segment 1 Pressure Setpoint [02]
if: then the module:
you select Press/Pos profile execution controls clamp close pressure to this setpoint after starting the First Clamp Close Profile
until clamp position reaches the larger of CPC11 or CPC61
CPC11 End of Segment 1 Position Setpoint [14]
CPC12 Segment 2 Velocity Setpoint [07] or [08]
if: then the module:
you select Vel/Pos profile execution controls clamp close speed to this setpoint from the clamp position CPC11 until clamp
position reaches the larger of CPC14 or CPC61
CPC03-B14 is RESET reads this parameter in percent velocity
CPC03-B14 is SET reads it in in.(mm)/s
CPC13 Segment 2 Pressure Setpoint [02]
if: then the module:
you select Press/Pos profile execution controls clamp close pressure to this setpoint from the clamp position CPC11 until clamp
position reaches the larger of CPC14 or CPC61
CPC14 End of Segment 2 Position Setpoint [14]
CPC15 Segment 3 Velocity Setpoint [07] or [08]
if: then the module:
you select Vel/Pos profile execution controls clamp close speed to this setpoint from the clamp position CPC14 until clamp
position reaches the larger of CPC17 or CPC61
CPC03-B14 is RESET reads this parameter in percent velocity
CPC03-B14 is SET reads it in in.(mm)/s
CPC16 Segment 3 Pressure Setpoint [02]
if: then the module:
you select Press/Pos profile execution controls clamp close pressure to this setpoint from the clamp position CPC14 until clamp
position reaches the larger of CPC17 or CPC61
CPC17 End of Segment 3 Position Setpoint [14]
Second Clamp Close Profile Setpoints
Word Description
CPC18 Segment 4 Velocity Setpoint [07] or [08]
if: then the module:
you select Vel/Pos profile execution controls clamp close speed to this setpoint after starting the Second Clamp Close Profile
until clamp position reaches the larger of CPC20 or CPC61
CPC03-B14 is RESET reads this parameter in percent velocity
CPC03-B14 is SET reads it in in.(mm)/s
CPC19 Segment 4 Pressure Setpoint [02]
if: then the module:
you select Press/Pos profile execution controls clamp close pressure to this setpoint after starting the Second Clamp Close
Profile until clamp position reaches the larger of CPC20 or CPC61
CPC20 End of Segment 4 Position Setpoint [14]
