2–9Command Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
CPC
Word Bit Description
B11 Mold Protection Zone Overrun Selection
= 0 Start Clamp Low Pressure Close Profile on Mold Protection Zone Overrun
= 1 Stop and Zero Outputs on Mold Protection Zone Overrun
During any of the first three Clamp Close Profiles,
if B11 is: then the module:
clamp position reaches a value immediately terminates the ongoing Clamp Close Profile and checks this bit
less than or equal to CPC61
RESET immediately begins the Clamp Low Pressure Close Profile
SET sets its outputs to zero
B12-B13 Open
B14 Velocity Units Selection
= 0 Velocity Parameters in Percent Velocity
= 1 Velocity Parameters in in.(mm)/s
if B14 is: then the module:
RESET returns all segment velocity actuals (and assumes all velocity setpoints) in units of percent velocity where
FCC46, SCC46, and TCC46 represent 100% velocity
SET returns all velocity actuals (and assumes all velocity setpoints) in units of in.(mm)/s
B15 Open
CPC04 Configuration Selections
Open/Closed Loop Selection
B00 = 0 Vel/Pos First Clamp Close Profiles Closed Loop
= 1 Vel/Pos First Clamp Close Profiles Open Loop
B01 = 0 Press/Pos First Clamp Close Profiles Closed Loop
= 1 Press/Pos First Clamp Close Profiles Open Loop
B02 = 0 Vel/Pos Second Clamp Close Profiles Closed Loop
= 1 Vel/Pos Second Clamp Close Profiles Open Loop
B03 = 0 Press/Pos Second Clamp Close Profiles Closed Loop
= 1 Press/Pos Second Clamp Close Profiles Open Loop
B04 = 0 Vel/Pos Third Clamp Close Profiles Closed Loop
= 1 Vel/Pos Third Clamp Close Profiles Open Loop
B05 = 0 Press/Pos Third Clamp Close Profiles Closed Loop
= 1 Press/Pos Third Clamp Close Profiles Open Loop
B06 Open
B07 = 0 Clamp Low Pressure Close Profiles Closed Loop
= 1 Clamp Low Pressure Close Profiles Open Loop
ERC Enabled/Disabled Selection
B08 = 0 Vel/Pos First Clamp Close Profiles ERC On
= 1 Vel/Pos First Clamp Close Profiles ERC Off
B09 = 0 Press/Pos First Clamp Close Profiles ERC On
= 1 Press/Pos First Clamp Close Profiles ERC Off
B10 = 0 Vel/Pos Second Clamp Close Profiles ERC On
= 1 Vel/Pos Second Clamp Close Profiles ERC Off
B11 = 0 Press/Pos Second Clamp Close Profiles ERC On
= 1 Press/Pos Second Clamp Close Profiles ERC Off
B12 = 0 Vel/Pos Third Clamp Close Profiles ERC On
= 1 Vel/Pos Third Clamp Close Profiles ERC Off
B13 = 0 Press/Pos Third Clamp Close Profiles ERC ON
= 1 Press/Pos Third Clamp Close Profiles ERC Off
B14 Open
B15 = 0 Clamp Low Pressure Close Profiles ERC On
= 1 Clamp Low Pressure Close Profiles ERC Off
CPC05 - 08 Open
