User Manual

2–8 Command Word/Bit Descriptions
Publication 1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
Word Description
CLC41 Ejector Full Retract Segment 3
CLC42 Reserved
CLC43 - 64 Open
Bit-mapped Control Words
Word Bit Description
CPC01 Block ID = 00000111 (low byte). High byte reserved for the module. Do not use.
CPC02 Open
CPC03 Configuration Selections
Profile Algorithm Selections
B00 = 0 Vel/Pos selected for First Clamp Close Profile
= 1 Press/Pos selected for First Clamp Close Profile
B01 Open
B02 = 0 Vel/Pos selected for Second Clamp Close Profile
= 1 Press/Pos selected for Second Clamp Close Profile
B03 Open
B04 = 0 Vel/Pos selected for Third Clamp Close Profile
= 1 Press/Pos selected for Third Clamp Close Profile
B05-B07 Open
B08 First/Second Clamp Close Logical Bridge Selection
= 0 Start Second Clamp Close Profile at End of First Clamp Close Profile
= 1 Stop and Set-output at End of First Clamp Close Profile
The module checks this pause bit at end of the First Clamp Close Profile to determine what further action to take:
if B08 is: then the module:
SET sets its outputs to FCC33 - FCC40
RESET and CPC20 > 00000 immediately begins the Second Clamp Close Profile
RESET and CPC20 = 00000 reacts as if it had just completed the Second Clamp Close Profile, and
continues operation based on the state of CPC03-B09
B09 Second/Third Clamp Close Logical Bridge Selection
= 0 Start Third Clamp Close Profile at End of Second Clamp Close Profile
= 1 Stop and Set-output at End of Second Clamp Close Profile
The module checks this pause bit at end of the Second Clamp Close Profile to determine what further action to take:
if B09 is: then the module:
SET sets its outputs to SCC33 - SCC40
RESET and CPC29 > 00000 immediately begins the Second Clamp Close Profile
RESET and CPC29 = 00000 reacts as if it had just completed the Second Clamp Close Profile, and
continues operation based on the state of CPC03-B10
B10 Third Clamp Close/Clamp Low Press Close (LPC) Logical Bridge Selection
= 0 Start Clamp LPC Profile at End of Third Clamp Close Profile
= 1 Stop and Set-output at End of Third Clamp Close Profile
The module checks this pause bit at end of the Third Clamp Close Profile to determine what further action to take:
if B10 is: then the module:
SET sets its outputs to TCC33 - TCC40
RESET immediately begins the Clamp Low Pressure Close Profile
CPC – Clamp Close
Profile Block
