2–7Command Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
CLC
Bit-mapped Control Words
Word Description
CLC01 Block ID = 00011011 (low byte). High byte reserved for the module. Do not use.
CLC02 - 08 Open
Clamp Close Profiles ERC Values
Word Description
CLC09 Segment 1 (First Clamp Close Profile)
CLC10 Segment 2 (First Clamp Close Profile)
CLC11 Segment 3 (First Clamp Close Profile)
CLC12 Segment 4 (Second Clamp Close Profile)
CLC13 Segment 5 (Second Clamp Close Profile)
CLC14 Segment 6 (Second Clamp Close Profile)
CLC15 Segment 7 (Third Clamp Close Profile)
CLC16 Segment 8 (Third Clamp Close Profile)
CLC17 Segment 9 (Third Clamp Close Profile)
CLC18 Segment 1 (Clamp Low Pressure Close Profile)
CLC19 Segment 2 (Clamp Low Pressure Close Profile)
Clamp Open Profiles ERC Values
Word Description
CLC20 Segment 1 (First Clamp Open Profile)
CLC21 Segment 2 (First Clamp Open Profile)
CLC22 Segment 3 (First Clamp Open Profile)
CLC23 Segment 4 (Second Clamp Open Profile)
CLC24 Segment 5 (Second Clamp Open Profile)
CLC25 Segment 6 (Second Clamp Open Profile)
CLC26 Segment 7 (Third Clamp Open Profile)
CLC27 Segment 8 (Third Clamp Open Profile)
CLC28 Segment 9 (Third Clamp Open Profile)
CLC29 Segment 1 (Clamp Open Slow Profile)
CLC30 Segment 2 (Clamp Open Slow Profile)
Ejector Profile ERC Values
Word Description
CLC31 Ejector Full Advance Segment 1
CLC32 Ejector Full Advance Segment 2
CLC33 Ejector Full Advance Segment 3
CLC34 Reserved
CLC35 Ejector Tip Retract Segment
CLC36 Reserved
CLC37 Ejector Tip Advance Segment
CLC38 Reserved
CLC39 Ejector Full Retract Segment 1
CLC40 Ejector Full Retract Segment 2
CLC – Clamp and Eject
ERC Values Block
