2–6 Command Word/Bit Descriptions
Publication
1771-6.5.88 – July 1997
Notes: 1. For [ ] engineering units, see page 3.
2. When using the Inject/Clamp/Eject mode, all pressure readings are system pressure at input 2, except where noted.
The QDC module will not accept or process the following command
(or status) blocks unless the module configuration includes an analog
input reserved for connection of a clamp position sensor (MCC02):
Command Block Status Block
CLC CLS
CPC CPS
FCC OPS
FOC
LPC
OPC
OSC
SCC
SOC
TCC
TOC
The module will not accept or process the following command (or status)
blocks unless the module configuration includes an analog input reserved
for connection of an ejector position sensor (MCC02), and the module
configuration indicates that the sensor is physically connected (MCC03):
Command Block Status Block
EAC EPS
EPC
ERC
The module will not accept or process the following command (or
status) blocks unless the module configuration includes an analog input
reserved for connection of a ram (screw) position sensor (MCC02):
Command Block Status Block
HDC HPS
HPC IPS
INC PPS
IPC PTS
PKC RLS
PLC
PRC
PSC
PTC
RLC
-
Sensors Required
